1200v耐压 高边/低边驱动器主要规格
功能安全:
特性：
channel
2
high-side floating supply voltage [v]
1200
turn-on/off time (typ.) [ns]
55
vcc(min.)[v]
10
vcc(max.)[v]
24
operating temperature (min.)[°c]
-40
operating temperature (max.)[°c]
125
package size [mm]
6.5x8.1 (t=2.01)
common standard
aec-q100 (automotive grade)
特点：
- aec-q100 qualified(grade 1)
- high-side floating supply voltage 1200v
- active miller clamping
- under voltage lockout function
- 3.3v and 5.0v input logic compatible
reference design / application evaluation kit
-
- evaluation board - bm60212fv-evk001
the bm60212fv-evk001 board can be driving igbt power devices for high-side and low-side on half-bridge application. the bm60212fv-c has power supply protections which are the under-voltage lockout (uvlo) function at vcca and vccb. the active miller clamping is included for gate control. the bm60212fv-evk001 allows designers to evaluate rohm’s gate driver family for various applications.
| user's guide |
|---|
